HT7 Disc Edger Floor Sander

$2,571.91

In stock

Product Code (PSTK): 07004
Pack Qty: 1
Price: Each

Description

The HT7 is a high performance disc floor sander (edger) that delivers unrivalled balance and feel. The choice of professionals, the HT7 delivers the power to tackle the toughest of jobs.

Precision engineered to meet the challenging demands of the tool rental, contractor and professional markets. A powerful four brush motor drives a dynamically balanced metal backed sanding pad. The drive is transmitted through a hardened steel alloy pinion and large diameter phosphor bronze drive gear that will not slip or stall when under heavy load. Motor commutation is via Hiretech’s precision moulded brush block with brass brush holders and constant force brush springs ensuring a smooth, constant power delivery.

Hiretech’s unique metal backed sanding pad gives the balance, feel and touch demanded by the professional craftsman, making it easy to sand a score free finish with a high production rate and fast stock removal when needed.

The HT7 Disc Floor Sander will sand a high quality, score-free finish on hard and soft wood floors, including parquet and any solid wood surface that requires rapid sanding and levelling. The HT7 can also be used on a wide range of other surfaces including some types of decking, fibre board, cork, composition and engineered floors. Ideal for confined areas such as closets, stair treads and sanding right up to the edge of a floor (edge sanding), without damage to the base board, mouldings or skirting.

HT7 Abrasive Starter Kit

  • Biased off ON/OFF switch prevents accidental start-up.
  • Powerful 1.5hp 4 pole (brush) motor geared 3:1.
  • Dynamically balanced metal backed sanding pad.
  • ABS disc guard with bronze insert prevents damage to mouldings and skirting.
  • Wheel castors allow easy change of direction.
  • Integrated dust bag support and cable caddy.
  • High powered vacuum system.
  • Disposable paper or cloth dust bags.
  • Storage for sanding pad wrench.
  • 2 year warranty.
HT7 Disc Edger Floor Sander Design Illustration
  1. Biased off switch with power connected indicator light, prevents accidental start-up.
  2. Precision moulded brush block with brass brush holders and constant force brush springs.
  3. Disposable paper bags for efficient and safe dust collection read more.
  4. Economic handle design minimises user fatigue. Handles securely support the HT7 in an upside-down position for easy changing of abrasive discs.
  5. Dust bag support folds upright to provide cable storage. 7m (23′) power cable with non-marking outer insulation prevents marking of newly sanded floor.
  6. Wheel castors allow HT7 to glide effortlessly across floor surface allowing easy changes in direction.
  7. Storage for sanding pad wrench.
  8. High powered vacuum system, with seated oversize wide bladed alloy vacuum fan.
  9. Hardened steel alloy pinion and large diameter phosphor bronze drive gear that will not slip or stall.
  10. Hiretech’s unique dynamically balanced metal backed sanding pad provides superb feel and touch and consistent sanding performance on all floor types.
  11. ABS disc guard freely rotates against base boards and skirting, preventing damage and protects the sanding pad.
  12. Polished aluminium alloy body.

ITEMSPECIFICATIONNOTES
ModelHT7-2
Product Codes07003 (220/240V)
07004 (110/120V)
V = Volts
Power Supply220/240V 50/60Hz
110/120V 50/60Hz
V = Volts
Hz = Hertz (unit of frequency)
Off Load Current220/240V = 5A
110/120V = 8A
A =Amps
Average Load Current220/240V = 8A
110/120V = 15A
A =Amps
Noise100 dBA at 1 meter (3’2″)dBA = decibels
Vibration2.71 m/s2 rmsm/s = meters per second, rms = root mean squared
SwitchBias off, double pole with power connected indicator light.
MotorContinuous heavy-duty AC/DC self cooling 4 brush motor.AC/DC = Alternating Current/Direct Current
Motor RPM13,000RPM = revolutions per minute

Mean rpm across voltage range, actual rmp will vary depending on voltage and condition of machine.

Disc RPM3,300RPM = revolutions per minute

Mean rpm across voltage range, actual rmp will vary depending on voltage and condition of machine.

Sanding Disc178mm (7″) dia. metal backed and rubber bonded high performance sanding pad.
DriveHardened steel alloy pinion and large diameter phosphor bronze drive gear.
Dust PickupSeated oversize alloy vacuum fan. Disposable paper dust bag or cloth bag.
Moving PartsSealed for life ball bearings.
GuardsHigh impact injection moulded ABS with bronze bush.
Abrasives178mm (7″) dia x 22mm (7/8“) dia slotted centre hole Recommended grit P24 to P120. Recommended type aluminium oxide or silicon carbide, backing E or F weight paper, bonding resin over resin with antistatic additives.
Power Cable7m (23′) Non-marking outer insulation.
Dimensions276mm x x505mm x 325mm
(10.8″ x 19.9″ x 12.8″)
width x depth x height

Maximum dimensions with handle fully extended and dust bag in operating position.

Weight Net16.4kg (36.2lbs)
Shipping Weight18.0kg (39.7lbs)
Shipping Dimensions390mm x 320mm x 350mm
(15.4″ x 12.6″ x 13.8″)
width x depth x height
Quantity per Pallet16Pallet size 1200mm x 1000mm
Warranty2 years
ApprovalsCE (220/240V)
CE (110/120V)
CSA/C US (110V North America)
CE = European Economic Area Manufacturer Certification

CSA/C US = Canadian Standards Association certified for USA and Canada

HT7 Parts List & Drawing

HT7 Owners Manual & Operating Instructions

HT7 Wiring Diagram
